AMADA LC-2415 A3 Laser cutting machine

This AMADA LC-2415 A3 Laser cutting machine was manufactured in the year 1999 in Japan. It is equipped with a FANUC Series 160i-L control unit and a FANUC C-3000 D laser with 3kW laser power. The laser can cut 12 mm mild steel and 6 mm stainless steel. See tech specs (DE) as PDF attached.

Overview

brand: AMADA
year: 1999
MODEL: LC-2415 A3
production hours: 32500
application type: Cutting
Location: Germany
machine type: CO2 Laser Cutting Machine
availability: Sold
control unit brand: FANUC

Technical Information - AMADA LC-2415 A3

General Data

Measurements width: 2500 MM
Measurements depth: 5654 MM
Measurements height: 2275 MM
Machine weight: 6400 kg

Control Unit

Model: Series 160i-L
Brand: FANUC

Main drive

Laserpower: 3 KW
Number of axis: 3

Movement

X-AXIS Movement: 2520 MM
X-AXIS Rapid traverse: 80 M/MIN
Y-AXIS Movement: 1550 MM
Y-AXIS Rapid traverse: 80 M/MIN
Z-AXIS Movement: 300 MM
Z-AXIS Rapid traverse: 60 M/MIN

Workpiece

Workpiece x: 5040 mm
Workpiece y: 1550 mm
Workpiece weight: 330 KG

Max Material thickness

Steel: 12 mm
Stainless steel: 6 mm

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Max. Cutting speed x- and y-axis 20 m/min
- - Max. Sheet dimensions 5040 x 1550 mm
- - Positioning accuracy 0. 01 mm/500 mm
- - Repeatability +/- 0. 005 mm
- - Height of the table 820 mm
- - Size of the opening 550 x 1550 mm
Qualitative Machine Benefits:
- - The laser can cut 12 mm mild steel and 6 mm stainless steel

Extra information

- Supply voltage 200 V (10 %) // Main frequency 50/60 Hz (1 Hz) // Installed power 10 k/A, 3 phases // Compressed air requirement (machine functions) 6 bar; 20 m3 / h // Compressed air requirement (compressed air as cutting gas) additional 17 bar; 63 m3 / h

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
