EMCO Maxxmill 350

Photo Gallery

EMCO - Maxxmill 350DE-MIL-EMC-2015-00001

Sold

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
Emco Maxxmill 350 Vertical Machining center

This Emco Maxxmill 350 Vertical Machining center was made in 2015 in Italy and has 14615 production hours. It is equipped with a HEIDENHAIN TNC 620 control unit and has 3+2 axis. The machine has a spindle speed of 12000 rpm, is in good condition and well maintained.

Overview

brand: EMCO
year: 2015
MODEL: Maxxmill 350
production hours: 14615
application type: Milling
Location: Germany
machine type: Vertical Machining Centre
availability: Sold
control unit brand: HEIDENHAIN

Technical Information - EMCO Maxxmill 350

General Data

Measurements width: 1630 mm
Measurements depth: 2300 mm
Measurements height: 2282 mm
Machine weight: 3300 kg

Control Unit

Model: TNC 620
Brand: HEIDENHAIN

Main drive

Number of spindles: 1
Spindle speed range: 12000 1/MIN
Spindle motor power: 7 kW
Number of axis: 3+2

Movement

X-AXIS Movement: 350 mm
Y-AXIS Movement: 250 mm
Z-AXIS Movement: 300 mm

Workpiece

Workpiece weight: 50 kg

Table

Outer length: 400 mm
Outer width: 400 mm

Tools

Slots in storage: 50
Max weight: 5 kg
Max tool diameter: 63/100 mm
Max tool length: 200 mm
Type of tool holder: DIN 30

Additional Information

Machine Benefits

Technical Machine Benefits:
- - B axis: +/- 100 degrees
- - 3+2 axis
- - C axis: 360 degrees (0. 001 degree increment)
- - Min - max height under spindle: 70 - 370mm
- - Rapid feed rates: 30m/minute
- - Swarf conveyor
Qualitative Machine Benefits:
- - Very good condition with low hours!

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
