Front view of Gildemeister CTX 310 V6 machine

Thank you for your visit

This machine was recently sold. Take a look at similar options or get in touch with us directly.

Browse all similar machines

Browse similar machines

Gildemeister CTX 310 V6

Photo Gallery

Gildemeister - CTX 310 V6PT-TUR-GIL-2006-00001

Sold

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
Gildemeister CTX 310 V6 lathe

This Gildemeister CTX 310 V6 lathe was built in 2006 in Italy. It is controlled by a Heidenhain PLUS IT control unit and has 4 axis. The machine has a main and a sub-spindle speed of 6000 rpm and is in perfect condition.

Overview

brand: Gildemeister
year: 2006
MODEL: CTX 310 V6
production hours: 0
application type: Turning
Location: Portugal
machine type: Horizontal Turning Machine
control unit brand: HEIDENHAIN

Technical Information - Gildemeister CTX 310 V6

General Data

Machine weight: 3950 kg

Control Unit

Model: PLUS IT
Brand: HEIDENHAIN

Main drive

Spindle speed range: 6000 1/MIN
Spindle motor power: 12 kW
Number of axis: 4

Movement

X-AXIS Movement: 140 mm
X-AXIS Feed Force: 4,5 kN
X-AXIS Rapid traverse: 24 m/min
Y-AXIS Movement: 80 (+/- 40) mm
Y-AXIS Feed Force: 9,0 kN
Y-AXIS Rapid traverse: 12 m/min
Z-AXIS Movement: 450 mm
Z-AXIS Feed Force: 4,5 kN
Z-AXIS Rapid traverse: 30 m/min
C-AXIS Movement: 360° MM
C-AXIS Rapid traverse: 100 / 2: 200 min/-1

Tools

Number of stations: 12
Type of tool holder: VDI 30

Additional Information

Machine Benefits

Qualitative Machine Benefits

Max. Speed sub spindle 6. 000 min/-1, power capacity - sub spindle 7,5 kw, max. Torque 48 nm
Subspindle z2 440 mm
Tool shank 20 x 20 mm
Max. Speed driven tool stations 4. 000 min/-1, power capacity - driven tool-stations 3,3 kw, max. Torque 16 nm
Rapid traverse sub spindle z2 30 m/min
Feeding force sub spindle z2 4,0 kn, total power requirement 32 kva

Technical Machine Benefits

Turning diameter max. 246 mm
Turning length max. 445 mm
Distance between spindles 665 mm
Center height 365 mm
Greatest pass round over bed 500 mm
Swing dia. Over traverse guideway 375 mm
Standard turning dia. 170 - 210 mm
Max. Torque 115 nm - c-axis 0,001 °
Spindle bearing diameter 100 mm - spindle bore 73 mm
Max. Usable bar diameter 50 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
