➤ Used +GF+ AGIE CHARMILLES VCE 800 PRO | Machining Center

This 3-axis +GF+ AGIE CHARMILLES VCE 800 PRO vertical machining centre was manufactured in 2014. It features a robust HEIDENHAIN iTNC530 control, a maximum spindle speed of 10,000 min/¹, and a tool holder of ISO 40. The work table measures 910x500 mm, supporting up to 1100 kg. Ideal for precision machining, it includes a 24-position tool changer. If you are looking to get high-quality milling capabilities consider the +GF+ AGIE CHARMILLES VCE 800 PRO machine we have for sale. Contact us for further details regarding this machine.

Overview

brand: +GF+
year: 2014
MODEL: AGIE CHARMILLES VCE 800 PRO
application type: Milling
Location: Italy
machine type: Vertical Machining Centre
control unit brand: HEIDENHAIN

Technical Information - +GF+ AGIE CHARMILLES VCE 800 PRO

General Data

Machine weight: 5000 KG

Control Unit

Brand: HEIDENHAIN
Model: iTNC530

Main drive

Spindle speed range: 10000 1/MIN
Spindle motor power: 12 kW
Tool taper: ISO 40
Number of axis: 3

Movement

X-AXIS Movement: 800 mm
Y-AXIS Movement: 500 mm
Z-AXIS Movement: 540 mm

Table

Outer length: 910 mm
Outer width: 500 mm
TSlots size: 18 +0.006/ + 0.024 mm
Number of tslots: 5
Distance between: 100 mm
Table load: 1100 kg

Tools

Slots in storage: 24
Max weight: 6 kg

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Tool holder spindle drive type: toothed belt
- - Torque at 100% ri: 96 nm
- - Tool change time: 6 sec
- - Tightening-loosening times according to vdi 2852: 8 sec
- - Coolant system capacity: 300 l
- - Machine supplied with manuals and ce declaration of conformity
- - Voltage: 50/60 hz
- - Consumption: 32 a
- - Connected load: 16 kw

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
