➤ Used Mazak Integrex i-400S- 2500U | Turn-Mill Centre

This 5-axis Mazak Integrex i-400S-2500U was manufactured in 2018, featuring Mazatrol SMOOTH X Control and a Hydrafeed MSV110 Barfeed. It offers a maximum machining diameter of ø658 mm and a length of 2,497 mm. Equipped with a milling spindle speed of 12,000 rpm and a tool storage capacity of 72 tools, this turn-mill centre is ideal for complex machining tasks. If you are looking to get high-quality turning and milling capabilities, consider the Mazak Integrex i-400S-2500U machine we have for sale. Contact us for more information.

Overview

brand: Mazak
year: 2018
MODEL: Integrex i-400S- 2500U
application type: Turning
Location: Croatia
machine type: Turn-Mill Centre
control unit brand: MAZATROL

Technical Information - Mazak Integrex i-400S- 2500U

Control Unit

Brand: MAZATROL
Model: SMOOTH X

Main drive

Number of spindles: 2
Spindle speed range: 1 - 3300 rpm 1/MIN
Spindle bore: ø112 mm (ø4.41 inches)
Number of axis: 5

Movement

X-AXIS Movement: 615 mm
X-AXIS Rapid traverse: 50 m/min
Y-AXIS Movement: 260 mm
Y-AXIS Rapid traverse: 40 m/min
Z-AXIS Movement: 2563 mm
Z-AXIS Rapid traverse: 40 m/min
W-Axis Rapid traverse: 30 m/min

Tools

Number of index: 72
Max weight: 12 kg
Max tool diameter: 90 mm
Type of tool holder: HSK-A63 (T63)

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Main spindle chuck size: 12 inches
- - Bearing id: ø150 mm (ø5. 91 inches)
- - Second spindle hydraulic chuck: 10 inches
- - Second spindle speed: 1 - 4000 rpm
- - Second spindle bore: ø91 mm (ø3. 58 inches)
- - Bearing id: ø130 mm (ø5. 12 inches)
- - B-axis indexing range: -30° to 210°
- - W-axis travel: 2175 mm (85. 63 inches)
- - When adjacent pockets empty: 125 mm (4. 92 inches) / 400 mm (15. 75 inches)

Extra information

- Max. Machining Diameter (Upper Turret): ø658 mm (ø25.9 inches) Max. Machining Length: 2497 mm (98.31 inches) Max. Bar Work Capacity: ø102 mm (ø4.02 inches) Boring Bar Shaft Diameter: ø40 mm (ø1.5 inches) B-axis Minimum Indexing Increment: 0.0001° Min. Main Spindle Indexing Increment: 0.0001°

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
